PromatRacking Schematic Drawing

Racking Schematic DrawingRacking Schematic Drawing
Schematic drawing:
W- Clear Width
D- Depth
H- Rack height

Parts:
» Upright: Vertical Steel member Lipped C Section to take compressive load.
» Beam: Box beam of varying section commensurate to the capacity. In case of shelved Flexi Rack, this beam is specially made step type to house panel (3)
» Panel/ shelves: Housed in the step slot of Beam (2), available in painted or GP. Horizontal and Diagonal bracing: Sub components to tie the structure and ensure depth required.
» Base plate: Base of the Uprights with a hole for Grouting bolt (Fixes the Racking system to the floor)
